General Purpose Needle Bracket (In-Plane)
Home >> Products & Solutions >> Biopsy Needle Guides >> Disposable Needle Guides >> General Purpose Needle Bracket (In-Plane)
-
-
Product features
Products Details
| Ref. no. | Model | Brands | Compatible transducers | Biopsy Angles |
| 10529 | DGC-0101 | / | Description:10/12/14/16/18/20/22,6F/8F/10F | Box:36 |
| 10530 | DGC-0102 | / | Description:11/13/15/17/19/21/23,7F/9F | Box:36 |
| 10660 | DGCK-0101 | / | Description:10/12/14/16/18/20/22,6F/8F/10F;20g gel;14x50cm TPU cover;2xelastic bands | Box:24 |
| 11109 | DGCK-0101 | / | Description:10/12/14/16/18/20/22,6F/8F/10F;20g gel;14x100cm TPU cover;2xelastic bands | Box:24 |
| 11110 | DGCK-0101 | / | Description:10/12/14/16/18/20/22,6F/8F/10F;20g gel;14x150cm TPU cover;2xelastic bands | Box:24 |
| 11117 | DGCK-0101 | / | Description:10/12/14/16/18/20/22,6F/8F/10F;20g gel;10x50cm TPU cover;2xelastic bands | Box:24 |
| 11111 | DGCK-0101 | / | Description:10/12/14/16/18/20/22,6F/8F/10F;20g gel;10x100cm TPU cover;2xelastic bands | Box:24 |
| 11112 | DGCK-0101 | / | Description:10/12/14/16/18/20/22,6F/8F/10F;20g gel;10x150cm TPU cover;2xelastic bands | Box:24 |
| 10661 | DGCK-0102 | / | Description:11/13/15/17/19/21/23,7F/9F;20g gel;14x50cm TPU cover;2xelastic bands | Box:24 |
| 11113 | DGCK-0102 | / | Description:11/13/15/17/19/21/23,7F/9F;20g gel;14x100cm TPU cover;2xelastic bands | Box:24 |
| 11114 | DGCK-0102 | / | Description:11/13/15/17/19/21/23,7F/9F;20g gel;14x150cm TPU cover;2xelastic bands | Box:24 |
| 11118 | DGCK-0102 | / | Description:11/13/15/17/19/21/23,7F/9F;20g gel;10x50cm TPU cover;2xelastic bands | Box:24 |
| 11115 | DGCK-0102 | / | Description:11/13/15/17/19/21/23,7F/9F;20g gel;10x100cm TPU cover;2xelastic bands | Box:24 |
| 11116 | DGCK-0102 | / | Description:11/13/15/17/19/21/23,7F/9F;20g gel;10x150cm TPU cover;2xelastic bands | Box:24 |
| 10472 | JSP-045 | ALPINION | SC1-4H, C1-6, C1-6T, C1-6i, C1-6CT, SC1-6, SC1-6H | 3(4cm), 2(7cm), 1(10cm) |
| 10473 | JSP-044 | ALPINION | L3-12, L3-12T, L3-12i, L3-12T | 3(1.5cm), 2(2.3cm), 1(3.2cm) |
| 10905 | JSP-185 | BK medical | 8823 | 18° |
| 10371 | JSP-031 | Canon | PVT-375AT, PVT-375AX, PVT-375BT, PVT-375ST, PVU-375BT, PVT-375SC | 52°, 64° |
| 10483 | JSP-055 | Canon | PVT-712BT, PVU-712BT | 51°, 63°, 69° |
| 10701 | JSP-074 | Canon | PLT-604AT, PLT-704AT, PLT-704SBT, PLT-704ST, PLU-704BT | 39°, 51° |
| 10703 | JSP-076 | Canon | PLT-805AT, PLT-1005BT, PLU-1005BT | 34°, 51° |
| 10466 | JSP-038 | CHISON | D7L40L, L7M-A, L7-E, L7-V, D12L40L, L12-E, L12-V | 40°, 50°, 60° |
| 10312 | JSP-002 | Esaote | CA541 | 15°, 25°, 35° |
| 10324 | JSP-005 | Esaote | CA421, CA430, CA431 | 20°, 30° |
| 10496 | JSP-068 | Esaote | AC2541, C1-8 | 15°, 25°, 35° |
| 10497 | JSP-069 | Esaote | SC3123, CA1123, mC3-11 | 20°, 35° |
| 10700 | JSP-073 | Esaote | LA522, LA523, LA532 | 40°, 55°, 70° |
| 10718 | JSP-091 | Esaote | SL1543, L4-15, LA533, AL2443 | 40°, 60° |
| 10311 | JSP-001 | GE | C1-5-D, C1-5-RS | 1(4cm), 2(6cm), 3(8.5cm) |
| 10332 | JSP-016 | GE | C1-6, C1-6-D, C1-6VN-D | 1(4cm), 2(6cm), 3(8.5cm) |
| 10356 | JSP-028 | GE | 11L, 12L, 11L-D, 12L-RS, 12L-SC, L6-12-RS | 1(1.5cm), 2(2.5cm), 3(3.5cm) |
| 10475 | JSP-047 | GE | 4C, 4C-A, 4C-D, 4C-RS, 4C-SC | 1(4cm), 2(6cm), 3(10cm) |
| 10478 | JSP-050 | GE | C2-7-D, C2-7VN-D | 1(3cm), 2(9cm) |
| 10479 | JSP-051 | GE | ML6-15-RS, ML6-15-D | 1(1.5cm), 2(2.5cm), 3(3.5cm) |
| 10494 | JSP-066 | GE | 3CRF, 3CRF-D | 13cm |
| 10499 | JSP-071 | GE | 9L, 9L-D, 9L-RS | 1(4cm), 2(5.5cm), 3(7cm) |
| 10709 | JSP-082 | GE | RAB6-D, RAB6-RS, RAB2-6-RS | 1(4cm), 2(6cm), 3(8cm) |
| 10711 | JSP-084 | GE | C2-9-D, C2-9VN-D | 1(3cm), 2(6cm), 3(8cm) |
| 10898 | JSP-178 | GE | 3Sc, 3Sc-RS | 1(4.6cm), 2(6.2cm), 3(8.2cm) |
| 10721 | JSP-094 | GE | L3-12-D, L3-12-RS | 1(1.5cm), 2(2.5cm), 3(3.5cm) |
| 10330 | JSP-014 | Fujifilm | EUP-L75, L64, UST-5417 | 41°, 49°, 61° |
| 10331 | JSP-015 | Fujifilm | EUP-L73s, L44 | 47° |
| 10480 | JSP-052 | Fujifilm | UST-979-3.5, UST-989(D)-3.5, UST-990-5, UST-9114-3.5, UST-9115-5, UST-9119, UST-9123, UST-9126, UST-9127 , UST-9130 | 25° |
| 10481 | JSP-053 | Fujifilm | C251, C35, C252, C253 | 17°, 25°, 32°, 47° |
| 10482 | JSP-054 | Fujifilm | UST-9133, C22K | 10°, 25 |
| 10702 | JSP-075 | Fujifilm | EUP-L74M, L55 | 44°, 51°, 60° |
| 10704 | JSP-077 | Fujifilm | EUP-C715, C25 | 17°, 25°, 32°, 47° |
| 10715 | JSP-088 | Fujifilm | UST-5415, L441 | 35°, 45°, 60° |
| 10837 | JSP-117 | Fujifilm | EUP-C532, C42 | 15°, 20°, 30° |
| 10726 | JSP-099 | SuperSonic | XC6-1, SC6-1(II), C6-1X | 1(14.8°), 2(20.4°), 3(26.6°), 4(33.7°) |
| 10305 | JSP-006 | Mindray | 3C5A, 3C5, 3C5s, 3C5P | 25°, 35°, 35° |
| 10307 | JSP-007 | Mindray | 7L4(s), 7L4A, 7L4B, 7L4P, 10L4(s), 7L5(s), 7L5P, L7-3(s), L7-3E, L11-4(s), L12-4(s), L12-3E, L14-6Ns, L14-6N | 40°, 50°, 60° |
| 10344 | JSP-022 | Mindray | C5-1s, C5-1E, C5-1U, SC6-1E, SC6-1U, SC6-1s, SC5-1Ns, C6-2, C6-2s, C6-2P | 25°, 35°, 45° |
| 10706 | JSP-079 | Mindray | C5-2, C5-2s, C5-2E | 25°, 35°, 45° |
| 10714 | JSP-087 | Mindray | SC5-1U, SC5-1E | 25°, 35°, 45° |
| 10716 | JSP-089 | Mindray | L14-5W, L14-5Ws, L14-5WE, L14-5WU | 47°, 53°, 59°, 65° |
| 10879 | JSP-159 | Mindray | L14-3U, L13-3Ns | 40°, 50°, 60° |
| 10334 | JSP-018 | Philips | C5-1(CX50, EPIQ, Affiniti) | D(5cm), C(9.6cm), B(13.3cm), A(20cm) |
| 10334P | JSP-018 | Philips | C5-1(IU22, IE33, HD15) | D(4.5cm), C(9cm), B(12cm), A(18cm) |
| 10373 | JSP-033 | Philips | L12-4(Affiniti and ClearVue), L12-3(Affiniti, EPIQ and CX50) | C(2cm), B(4cm), A(6cm) |
| 10468 | JSP-040 | Philips | V6-2 | B(5cm), A(8cm) |
| 10488 | JSP-060 | Philips | L12-5 50 | 1-66°, 2-54°, 3-44° |
| 10490 | JSP-062 | Philips | S5-1 | C(3cm), B(6.5cm), A(10cm) |
| 10708 | JSP-081 | Philips | C6-2, C6-3 | D(4cm), C(6cm), B(8.5cm), A(12cm) |
| 10713 | JSP-086 | Philips | eL18-4 | C(5cm), B(2.5cm), A(1.5cm) |
| 10727 | JSP-100 | Philips | V9-2 | 3-31°, 4-22°, 5-16° |
| 10326 | JSP-009 | Samsung | V4-8, VE4-8 | 6.5cm |
| 10379 | JSP-035 | Samsung | CA1-7A, CA1-7AD | A(5cm), B(10cm),C(15cm) |
| 10380 | JSP-036 | Samsung | P1-4, PE2-4 | B(4.5cm), A(9cm) |
| 10469 | JSP-041 | Samsung | C2-8A, CA2-8A, CA2-8AD, CA2-9A, CA2-9AD, CF2-8 | A(10cm), B(8cm),C(6cm) |
| 10500 | JSP-072 | Samsung | L3-12A, LA3-12A, LA3-14AD, L5-13/50, LA2-14A | A(4cm), B(2.5cm) |
| 10352 | JSP-024 | Siemens | 4V1, PH4-1 | A(32°), B(18°) |
| 10360 | JSP-029 | Siemens | 4C1, 6C1 HD | A(4.4cm), B(8.5cm) |
| 10362 | JSP-030 | Siemens | 9L4, VFX9-4, VF7-3, VF10-5, 11L4 | A(4cm), B(8cm) |
| 10372 | JSP-032 | Siemens | CH4-1, CH5-2, 5C1(Juniper) | A(2.1cm), B(5.4cm) |
| 10707 | JSP-080 | Siemens | 18L6HD, 18L6(Sequoia) | 2-39°, 3-29°, 4-20° |
| 10717 | JSP-090 | Siemens | 5C1(Sequoia), 6C1(Juniper) | 1-50°, 2-38°, 3-28° |
| 10722 | JSP-095 | Siemens | 10L4 | 20°, 27°, 38° |
| 10902 | JSP-182 | SIUI | C3L60, C3LC, C3L60C | 45°, 55°, 63° |
| 10333 | JSP-017 | SonoScape | L741 | 17°, 25°, 32°, 47° |
| 10471 | JSP-043 | SonoScape | 3C-A | 12°, 17°, 23°, 34° |
| 10931 | JSP-211 | SonoScape | C344 | 45° |
| 10836 | JSP-116 | SonoScape | L752 | 45° |
| 10726 | JSP-099 | Supersonic | XC6-1, SC6-1(II), C6-1X | 1(14.8°), 2(20.4°), 3(26.6°), 4(33.7°) |
| 10347 | JSP-023 | Terason | 5C2A | 9.5cm |
| 10487 | JSP-059 | TUORen | L38T7C | 40°, 48°, 61° |
| 10355 | JSP-026 | VINNO | X6-16L | A(1.5cm), B(2.5cm), C(3.5cm) |
| 10467 | JSP-039 | VINNO | X4-12L | A(2cm), B(4cm), C(6cm) |
——————Contact Sales for More Models
——————
